Distribution Box ah hian a awm

Distribution Box siamtu a ni

Distribution box hi electrical power him taka sem darh thei tura siam a ni a, chutih rualin circuit te chu overload leh short circuit atanga venhim a ni bawk. Electrical component-te chu enclosure him takah an dahkhawm a, chu chu awlsam taka dah, hman leh enkawl dan tur a ni.

Technical lam thil chi hrang hrang

Technical Parameter a ni	Standard Range & duhthlan tur hrang hrang
Ingress venhimna (IP Rating) a ni.	IP55, IP65, IP66, IP67, IP69K (IEC 60529 zawm tur) te hi a ni.
Impact laka invenna (IK Rating) 1.1.	IK08 (5 Joules), IK10 (20 Joules impact protection)
Rated Operational Voltage a ni	690V AC / 1000V DC thleng (Ni lama hman tur)
Rated Current a ni	10A atanga 800A (Busbar configuration custom a awm)
Material Thickness a ni	Sheet steel: 1.2mm, 1.5mm, 2.0mm te a ni a; A dahna plate: 1.5mm–2.5mm galvanized steel a ni
Standard Surface rawng hrang hrang	RAL 7035 (Light Grey), RAL 7032 (Pebble Grey), emaw, corporate rawng hrang hranga siam theih a ni
Operating Temperature a ni	-40℃atanga +85℃(-40℃F atanga +185℃F) thleng a ni.

Thil pawimawh tak tak

Polyurethane Gasket Seal chhunzawm zel

Foam-in-place polyurethane gaskets hian kawngkhar vel chu seal chhunzawm zel a pe a, hei hian enclosure venhimna vawng reng turin a pui a ni.

Corrosion-Resistant Surface Finish a ni

Steel enclosure te hi degreasing, iron-phosphate pretreatment, leh epoxy-polyester powder coating hmanga enkawl a ni a, hei hian corrosion resistance a ti tha zawk a ni.

Thermal & Moisture control dan tur ruahmanna siam a ni

Optional ventilation louvers, breather valve, leh anti-condensation heater te hian temperature inthlak danglamna avanga chhungril lama tui awm chu a tihziaawm thei a ni.

Internal Components & Integration duhthlan tur hrang hrang

DIN Rail leh Mounting Plate te chu:Zinc-plated 35mm DIN rails (IEC 60715) chu a san zawng-adjustable standoff bracket-a dah a ni.

Copper Busbars leh Neutral/Ground Blocks te chu a hnuaia mi ang hian a ni.Nickel-plated high-conductivity electrolytic copper busbars (E-Cu) 800A thlenga rated, touch-proof insulating shrouds vuah a ni.

Protective Component inzawmkhawmna:Brand lian (Schneider, ABB, Siemens, Chint) emaw client-specified equivalents atanga MCB, MCCB, RCCB, Surge Protective Devices (SPD), leh digital power meter te tan optional pre-wiring.

Cable enkawl dan: 1.1.Nylon/brass waterproof cable glands, rubber stepped grommets, leh a chhunga PVC wiring duct te a awm bawk.

Industry lama hman tur hrang hrang

Industrial Automation & Thil siamna hmun hrang hrang

Factory environment-a oil mist leh vibration-a inhnamhnawih motor starter, PLC controller, leh terminal block te dah a ni.

Ni zung hmanga PV & Energy dahkhawmna (ESS) .

Weatherproof combiner box leh AC/DC isolation panel te chu pawn lama ni zung rei tak awm theihna tur leh DC voltage sang tak neih theihna tura siam a ni.

Sumdawnna atana hman tur Real Estate & Infrastructure te a ni

Office complex, shopping center, leh chenna in sakna atana hman tur sub-distribution board thup leh lei chung-mounted.

Offshore, Marine & Coastal-a hmanraw awmte

Grade 316L stainless steel enclosure chu chi-spray exposure leh tuipui kama khaw lum nasa tak tuar thei tura engineer a ni.

Hun eng emaw chen atana In sakna Power

Jobsite hmanrua hun eng emaw chen atana hman tur RCD venhimna hmanga thuam, high-impact portable socket box.

Customization theihna te

CNC Cutouts dik tak chu:Digital display, push button, status indicator, leh gland plate luh dan tur custom door cutouts te a awm bawk.

Custom Dimensions & Structural Form Factors te chu a hnuaia mi ang hian a ni.Non-standard san zawng, zau zawng, thuk zawng tehna, emaw specialized dual-door enclosure emaw.

Surface Finish leh Branding te chu a hnuaia mi ang hian a ni.Powder coating chu RAL color swatches dik tak, laser-engraved nameplate, leh silk-screened brand logo nena inmil.

Contract Assembly leh Wiring siam dan tur: 1.1.Wiring assembly kimchang leh point-to-point continuity testing chu schematic diagram pek angin.

Order siam dan tur

Rahbi	Indawtdan	Hrilhfiahna
01	I Mamawhte chu thawn rawh	I drawing te, specification te, application details te chu share ve rawh.
02	Quotation & DFM thlirletna a ni	I project kan enfiah a, engineering recommendation nen quotation kan pe bawk.
03	Sample pawmpuina pek a ni	Custom sample hi mass production hmain test leh approval atan siam a ni.
04	Mass Production a ni	ISO 9001 quality management khauh tak hnuaiah production tan a ni.
05	Quality Inspection neih a ni	Order tin hian dimensional, appearance, leh functional inspection an nei vek a ni.
06	Packaging & Shipping te pawh a awm bawk	Products te hi him takin an pack a, khawvel hmun hrang hrangah tuipui, boruak emaw》emaw hmangin an thawn chhuak thin.
07	After-Sales Support	Order tin atan technical support leh rang taka after-sales service kan pe thin.

Thil siam chhuahna lama chakna

Kan ISO 9001 a ni

Kum 2015-a certified production facility hian volume siamna rintlak tak a pe a:

CNC Sheet Metal hmanga siam chhuah a ni

High-precision fiber laser cutting machine, multi-axis CNC turret punch press, leh automated hydraulic bending brake te a awm bawk.

Gasket Foaming hmanga siam chhuah a ni

Multi-axis CNC polyurethane dispensing machinery hian gasket profile geometry leh seal adhesion inmil tak a tichiang a ni.

Production Throughput a ni

Thla tin metal enclosure 50,000+ leh plastic enclosure 100,000+ siam chhuah theih a ni a, standard sample turnarounds chu ni 3–5 chhungin a ni.

Quality Control dan tur ruahmanna siam a ni

01/

Ingress laka invenna testing: 1.1.IPX5 / IPX6 high-pressure water spray test leh IP6X dust-chamber testing hmanga seal tightness finfiahna.

02/

Coating Adhesion & Thickness testing te hi a hnuaia mi ang hian a ni.Cross-hatch tape test leh magnetic thickness gauge hmanga powder coat adhesion finfiahna.

03/

IK Mechanical Impact Testing hmanga thil tih dan: 1.1.Drop-hammer impact testing hmanga structural integrity chu taksa chakna laka finfiah a ni.

04/

Electrical Continuity & Insulation Testing hmanga thil tih dan tur:Assembled unit-ah high-voltage dielectric testing leh earth bonding continuity check a ni.

Packaging & Khawvel pum huapa thawn chhuah

Hriselna atana hman tur Packaging

Mimal PE film wrapping, reinforced corner protector, thick corrugated inner carton, leh fumigation-free plywood pallets stretch film-a khuh.

Transit a rei theihna tur

Tuipuia container bungraw phurh emaw, thlawhna hmanga thawn chhuah hunah painted surface leh door hinge venhimna atana siam, verified packaging drop-test.

Logistics chungchanga thupek

Shipping term supported-ah hian EXW, FOB, CIF, DDP (Delivered Duty Paid) te a tel a, contractor warehouse site-a direct-a thawn theihna tur drop-shipping option a awm bawk.

Certification pek chhuah a ni

ISO 9001 quality management hnuaia siam a ni a, project mamawh angin CQC certification leh certification dangte pawh a awm bawk.

FAQ

Q: IP65 leh IP66 distribution box te hi eng nge an danglamna ber?

A: IP65 enclosures hian eng lam atanga low-pressure water jets lakah a venghim. IP66 enclosure hian high-pressure water jet leh tuifinriat rit tak lakah venhimna a pe a, hei vang hian pawn lama khaw lum emaw, direct washdown emaw avanga hmuna awmte tan chuan a tha zawk a ni.

Q: Kan CAD emaw 3D emaw drawing atang hian direct in distribution enclosure i siam thei em?

A: Ni e. DWG, DXF, STEP, leh IGES file format te kan pawm a. Kan engineering team hian prototyping hmain tolerances, hole placement, leh structural integrity te finfiah nan Design for Manufacturability (DFM) review an nei thin.

Q: I enclosure te hi North American UL 508A standards nen a inmil em?

A: Kan metal leh non-metallic enclosure te hi UL 508A leh NEMA 4/4X specification angin design leh siam a ni a, hei hian panel builder leh USA leh Canada-a export tur OEM te tan a tha hle.

Q: Engtin nge pawn lam enclosure atan 304 leh 316L stainless steel hi ka thlan theih ang?

A: Grade 304 stainless steel hian standard outdoor environment atan general corrosion resistance a pe a. Grade 316L-ah hian molybdenum dah belh a ni a, chloride leh salt spray laka invenna tha zawk a pe a, hei vang hian tuipui leh tuipui kama hman atan a tha hle.

Q: Enclosure hrui hring chauh i hralh em, a nih loh leh fully assembled distribution board i hralh em?

A: Option pahnih hi kan pe vek. Enclosure hrui hring, cutout leh backplate nei customized enclosure, circuit breaker, terminal block leh busbar dahna fully wired distribution assembly emaw order theih a ni.

Q: Custom-sized enclosure atana i Minimum Order Quantity (MOQ) chu engzat nge ni?

A: Standard stock enclosure-ah hian minimum order tih tur a awm lo. Custom size emaw specialized powder coating colors tan chuan kan MOQ pangngai hi dimension a zirin unit 20 atanga 50 atanga tan a ni.

Q: Engtin nge pawn lama tui tlak lohna hmuna internal moisture condensation i ven theih ang?

A: Tui block laiin internal/external air pressure balance thei pressure equalization breather valve (vent plug) kan supply a. High-humidity hmun atan chuan internal anti-condensation heating elements kan integrate thei a ni.

Q: Bulk order atan i production lead time pangngai chu engzat nge ni?

A: Custom prototype te chu ni 3 atanga ni 7 chhungin an siam fel vek tawh. Bulk production order hian a tlangpuiin drawing sign-off leh deposit receipt atanga calendar ni 15 atanga ni 20 chhung a la a ni.

Q: Full production order kan siam hmain customized sample kan order thei ang em?

A: Ni e, sample prototyping kan fuih a ni. I mamawh CNC cutouts, color powder coating, leh branding te nen sample kan pe a. Sample fee hi i bulk order hnuhnung ber atan i credit thei ang.

Q: I distribution enclosure-ah hian eng warranty coverage nge i pek?

A: Standard operating condition hnuaiah structural enclosure integrity, powder coating durability, leh gasket seal te kum 3 chhung warranty kan pe a. Integrated electrical components hian siamtu warranty (a tlangpuiin thla 12–24) a keng tel a ni.

China rama distribution box siamtu leh supplier professional ber pawl kan nih angin customized service pawh kan thlawp bawk. Kan factory atang hian hetah hian discount distribution box stock ah wholesale in min rawn lei thei ang. Product quality tha tak tak leh man tlawm tak tak a awm bawk.
